VCCI to GND .....................................................................-0.3V, +7V VBATT1 to GND................................................................. -0.3V, +7V VBATT2 to GND................................................................. -0.3V, +7V VCCO to GND.......................................................... -0.3V, VS + 0.3V (VS = greater of VCCI, VBATT1, VBATT2) Digital Input and Output Voltages to GND............ 0.3V, VCCI + 0.3V Continuous Power Dissipation (TA = +70) 8-Pin Plastic DIP (derate 9.09mW/ above +70) ..............727mW 8-Pin SO (derate 5.88mW/ above +70)...........................471mW 16-Pin Wide SO (derate 9.52mW/ above +70)................762mW 8-Pin CERDIP (derate 8.00mW/ above +70)...................640mW Operating Temperature Ranges MXD1210C_ _ .............................................................. 0 to +70 MXD1210E_ _ ........................................................... -40 to +85 MXD1210MJA........................................................... -55 to +125 Storage Temperature Range .................................. -65 to +150 Lead Temperature (soldering, 10sec) .................................. +300 Stresses beyond those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
