SBT211-01, SBT2222, SBT2222AF Selling Leads, Datasheet
MFG:FRONTIER Package Cooled:SOT-23 D/C:N/A
SBT211-01, SBT2222, SBT2222AF Datasheet download
Part Number: SBT211-01
MFG: FRONTIER
Package Cooled: SOT-23
D/C: N/A
SBT211-01, SBT2222, SBT2222AF
- Table of contents:
Info of SBT211-01
Info of SBT2222
Info of SBT2222AF
Attentive hint
Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.
Top Sellers:
TOP
About SBT10100
PDF/DataSheet Download
Datasheet: SBT10100
File Size: 396735 KB
Manufacturer: Diotec Semiconductor
Download : Click here to Download
About SBT2222
PDF/DataSheet Download
Datasheet: SBT2222
File Size: 196205 KB
Manufacturer: AUK [AUK corp]
Download : Click here to Download
About SBT2222AF
PDF/DataSheet Download
Datasheet: SBT2222AF
File Size: 195729 KB
Manufacturer: AUK [AUK corp]
Download : Click here to Download
SBT2222 General Description
• General purpose application
• Switching application
SBT2222 Maximum Ratings
|
Characteristic |
Symbol | Ratings | Unit |
| Collector-Base voltage | VCBO | 60 | V |
| Collector-Emitter voltage | VCEO | 30 | V |
| Emitter-base voltage | VEBO | 5 | V |
| Collector current | IC | 600 | mA |
| Collector dissipation | PC* | 350 | mW |
| Junction temperature | Tj | 150 | °C |
| Storage temperature range | Tstg | -55~150 | °C |
SBT2222 Features
• Low Leakage current
• Low collector saturation voltage enabling low voltage operation
• Complementary pair with SBT2907
SBT2222 Connection Diagram
SBT2222AF General Description
• General purpose application
• Switching application
SBT2222AF Maximum Ratings
|
Characteristic |
Symbol | Ratings | Unit |
| Collector-Base voltage | VCBO | 75 | V |
| Collector-Emitter voltage | VCEO | 40 | V |
| Emitter-base voltage | VEBO | 5 | V |
| Collector current | IC | 600 | mA |
| Collector dissipation | PC* | 350 | mW |
| Junction temperature | Tj | 150 | °C |
| Storage temperature range | Tstg | -55~150 | °C |
SBT2222AF Features
• Low Leakage current
• Low collector saturation voltage enabling low voltage operation
• Complementary pair with SBT2907AF
SBT2222AF Connection Diagram
