The NB6L239 is a high−speed, low skew clock divider with two divider circuits, each having selectable clock divide ratios; ÷1/2/4/8 and ÷2/4/8/16. Both divider circuits drive a pair of differential LVPECL outputs. (More device information on page 7).
NB6L239 Maximum Ratings
Symbol
Parameter
Condition 1
Condition 2
Rating
Units
VCC
Positive Mode Power Supply
VEE = 0 V
3.6
V
VI
Input Voltage
VEE = 0 V
VEE VI VCC
3.6
V
Iout
Output Current
Continuous Surge
50 100
mA mA
IBB
VBBAC Sink/Source
± 0.5
mA
TA
Operating Temperature Range
−40 to +85
Tstg
Storage Temperature Range
−65 to +150
JA
Thermal Resistance (Junction−to−Ambient)
0 lfpm 500 lfpm
41.6 35.2
/W /W
JC
Thermal Resistance (Junction−to−Case)
Standard Board
4.0
/W
Tsol
Wave Solder
< 3 sec @ 248°C
265
Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device unctional operation is not implied, damage may occur and reliability may be affected.
NB6L239 Features
• Maximum Clock Input Frequency, 3.0 GHz • Input Compatibility with LVDS/LVPECL/CML/HSTL • Rise/Fall Time 70 ps Typical • < 10 ps Typical Output−to−Output Skew • Ex. 622 MHz Input Generates 38.8 MHz to 622 MHz Outputs • Internal 50 Termination Provided • Random Clock Jitter < 1 ps RMS • Divide−by−1 Edge of QA Aligned to QB Divided Output • Operating Range: VCC = 2.375 V to 3.465 V with VEE = 0 V • Master Reset for Synchronization of Multiple Chips • VBBAC Reference Output • Synchronous Output Enable/Disable
