MFG:Clare Category:ICs, Integrated Circuits, Semiconductors Package Cooled:SOP D/C:N.A
ITC117P, ITC117PTR, ITC117PX Datasheet download
Category: ICs, Integrated Circuits, Semiconductors
MFG: Clare
Package Cooled: SOP
D/C: N.A
Description: IC OPT-ISOLATED MULTIFUNC 16SOIC
Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.
TOP
PDF/DataSheet Download
Datasheet: ITC117P
File Size: 431104 KB
Manufacturer: CLARE [Clare, Inc.]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: ITC1000
File Size: 52129 KB
Manufacturer: ETC [ETC]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: ITC1000
File Size: 52129 KB
Manufacturer: ETC [ETC]
Download : Click here to Download
| Technical/Catalog Information | ITC117P |
| Vendor | Clare |
| Category | ICs, Integrated Circuits, Semiconductors |
| Application | Telecommunication |
| Type | Telecom Circuit |
| Mounting Type | Surface (SMD, SMT) |
| Package Name | 16-SOIC |
| Supply Voltage | 5.00 V [Typ] |
| Packaging | Tube |
| Operating Temperature | -40 °C [Min] |
| Operating Temperature | 85 °C [Max] |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | ITC117P ITC117P CLA131 ND CLA131ND CLA131 |
The Integrated Telecom Circuit combines a 1-Form-A solid state relay, bridge rectifier, Darlington transistor and optocoupler into one 16 pin SOIC package, consolidating designs and reducing component count in telecom applications. The ITC117's optocoupler provides for full wave detection of ring signals.
| Parameter | Min | Typ | Max | Units |
| Total Package Dissipation | - | - | 11 | W |
| Isolation Voltage | - | |||
| Input to Output | 3750 | - | - | VRMS |
| Operational Temperature | -40 | - | +85 | |
| Storage Temperature | -40 | - | +125 | |
| Soldering Temperature (10 Seconds Max.) |
- | - | +220 |
1 Above 25° derate linerity 8.33mw/°C
Total Power Dissipation (PD):
PD=PHOOKSWITCH + PBRIDGE + PDARLINGTON + PLED
PD=(RDS(on)) (I2L) + 2(VF)(IL) + (VCE)(IL) + (VLED)(IF)
WHERE:
RDS(on) = Maximum realy on resistance
IL = Maximum loop current
VF = Maximum diode forward voltage
VCE = Maximum voltage collector to emitter
VLED = Maximum LED forward voltage
IF = Maximum LED current
Absolute Maximum Ratings are stress ratings. Stresses in excess of these ratings can cause permanent damage to the device. Functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this data sheet is not implied. Exposure of the device to the absolute maximum ratings for an extended period may degrade the device and effect its reliability.
| Technical/Catalog Information | ITC117PTR |
| Vendor | Clare |
| Category | ICs, Integrated Circuits, Semiconductors |
| Application | Telecommunication |
| Type | Telecom Circuit |
| Mounting Type | Surface (SMD, SMT) |
| Package Name | 16-SOIC |
| Supply Voltage | 5.00 V [Typ] |
| Packaging | Tape & Reel |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | ITC117PTR ITC117PTR |
