W942508CH

W942508CH is a CMOS Double Data Rate synchronous dynamic random access memory (DDR  SDRAM), organized as 8,388,608 words * 4 banks * 8 bits. Using pipelined architecture and 0.13 m process technology, W942508CH delivers a data bandwidth of up to 400M words per second (-5). To fully comply with the personal computer industrial standard, W942508CH is sorted into four speed grades: -5, -6, -7, -75 The -5 is compliant to the 200MHz/CL2.5 & CL3 specification, The -6 is compliant to the 166MHz/CL2.5 specification, the -7 is compliant to the 143MHz/CL2.5 or DDR266/CL2 specification, the -75 is compliant to the DDR266/CL2.5 specification.

All Inputs of W942508CH reference to the positive edge of CLK (except for DQ, DM, and CKE). The timing reference point for the differential clock is when the CLK and CLK signals cross during a transition. And Write and Read data are synschronized with the both edges of DQS (Data Strobe).

By having a programmable Mode Register, the system can change burst length, latency cycle, interleave or sequential burst to maximize its performance. W942508CH is ideal for main memory in high performance applications.
