Product Details

Description



Features:

• Fast Access Time 8,10,12ns(Max.)
• Low Power Dissipation
  Standby (TTL) : 50mA(Max.)
            (CMOS) : 10mA(Max.)
  Operating KM641003B - 8 : 150 mA(Max.)
                  KM641003B - 10 : 145 mA(Max.)
                  KM641003B - 12 : 140 mA(Max.)
• Single 5.0V±10% Power Supply
• TTL Compatible Inputs and Outputs
• I/O Compatible with 3.3V Device
• Fully Static Operation
  - No Clock or Refresh required
• Three State Outputs
• Center Power/Ground Pin Configuration
• Standard Pin Configuration
                        KM641003BJ : 32-SOJ-400


Pinout

Connection Diagram


Description

The KM641003B is a 1,048,576-bit high-speed Static Random Access Memory organized as 262,144 words by 4 bits. The KM641003B uses 4 common input and output lines and has an output enable pin which operates faster than address access time at read cycle. The device is fabricated using SAMSUNG ,s advanced CMOS process and designed for high-speed circuit technology. It is particularly well suited for use in high-density high-speed system applications. The KM641003B is packaged in a 400 mil 32-pin plastic SOJ.
