S7136SF General Description

• As Control Circuit of Battery-Backed Memory
• As Measure Against Erroneous Operations at Power On-Off
• As Resetting Function for the CPU-Mounted Equipment --- PC, Printer, VTR, Fax, C-TV etc.
• As Measure Against System Runaway at Instantaneous Break of Power Supply etc.

S7136SF Maximum Ratings

Characteristic	Symbol	Ratings	Unit
Supply voltage	V_CC	-0.3 ~ +15	V
Power Dissipation (Package Limitation)	P_D^*	300	㎽
Operating Temperature	T_opr	-30 ~ +75
Storage Temperature	T_stg	-55 ~ +150

* With PCB(8*8 Copper Area) at Glass Epoxy Board (t=1.7 , Area; 20*20 )

S7136SF Features

• Current Consumption is Low (I_CCL=300 ㎂ Typ. I_CCH=30 ㎂ Typ.)
• Resetting Output Minimum Guarantee Voltage is Low (0.8V Typ.)
• Hysteresis Voltage is Provided (50 ㎷ Typ.)

S7136SF Connection Diagram
