S4580 General Description
| S4580 is the dual operational amplifier, specially designed for improving the tone control, which is most suitable for the audio application. Featuring noiseless, higher gain bandwidth, high output current and low distortion ratio, and it is most suitable not only for acoustic electronic parts of audio pre-amp and active filter, but also for the industrial measurement tools. |
S4580 Connection Diagram
S4580P General Description
| S4580 is the dual operational amplifier, specially designed for improving the tone control, which is most suitable for the audio application. Featuring noiseless, higher gain bandwidth, high output current and low distortion ratio, and it is most suitable not only for acoustic electronic parts of audio pre-amp and active filter, but also for the industrial measurement tools. |
S4580P Maximum Ratings
|
Characteristic |
Symbol |
Ratings |
Unit |
| Supply voltage |
VCC |
±18 |
V |
| Differential input voltage |
VID |
±30 |
V |
| Input voltage |
VIC(note) |
±15 |
V |
| Output current |
IO |
±50 |
mA |
| Power Dissipation |
PD* |
800 |
mW |
| Operating temperature |
Topr |
-40 ~ +85 |
|
| Storage temperature |
Tstg |
-55 ~ +125 |
(note) For supply voltage less than ±15V, the absolute maximum input voltage is equal to the supply voltage.
S4580P Features
• Operating voltage. (±2V ~ ±18V)
• Low input noise voltage. (0.8 ㎶ rms typ.)
• Wide gain bandwidth product. (15MHz typ.)
• Low distortion. (0.0005% typ.)
• Slew rate.
• Low input noise voltage. (0.8 ㎶ rms typ.)
• Wide gain bandwidth product. (15MHz typ.)
• Low distortion. (0.0005% typ.)
• Slew rate.
S4580P Connection Diagram
