MFG:Fairchild Semiconductor Category:Integrated Circuits (ICs) Package Cooled:DIP-7 D/C:08+
FSQ510, FSQ510-BULKLF STOCK 6000 FAIRCHILD - 0.2326, FSQ60A03LE Datasheet download
Category: Integrated Circuits (ICs)
MFG: Fairchild Semiconductor
Package Cooled: DIP-7
D/C: 08+
Description: IC SWITCH FPS 0.5A 700V 7-DIP
Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.
TOP
PDF/DataSheet Download
Datasheet: FSQ0270RNA
File Size: 969807 KB
Manufacturer: Fairchild Semiconductor
Download : Click here to Download
PDF/DataSheet Download
Datasheet: FSQ0270RNA
File Size: 969807 KB
Manufacturer: Fairchild Semiconductor
Download : Click here to Download
PDF/DataSheet Download
Datasheet: FSQ0270RNA
File Size: 969807 KB
Manufacturer: Fairchild Semiconductor
Download : Click here to Download
| Technical/Catalog Information | FSQ510 |
| Vendor | Fairchild Semiconductor |
| Category | Integrated Circuits (ICs) |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | FSQ510 FSQ510 |
A Valley Switching Converter (VSC) generally shows lower EMI and higher power conversion efficiency than a conventional hard-switched converter with a fixed switching frequency. The FSQ510 (H or M) is an integrated valley switching pulse width modulation (VS-PWM) controller and SenseFET specifically designed for offline switch-mode power supplies (SMPS) for valley switching with minimal external components. The VS-PWM controller includes an integrated oscillator, under-voltage lockout (UVLO), leading-edge blanking (LEB), optimized gate driver, internal soft-start, temperature-compensated precise current sources for loop compensation, and self-protection circuitry.
Compared with discrete MOSFET and PWM controller solutions, the FSQ510 (H or M) can reduce total cost, component count, size and weight; while simultaneously increasing efficiency, productivity, and system reliability. This device provides a platform for cost-effective designs of a valley switching flyback converters.
| Product | Product status | Eco Status | Pricing* | Package type | Leads | Packing method | Package Drawing | Package Marking Convention** |
|---|---|---|---|---|---|---|---|---|
| FSQ510 | Full Production | RoHS Compliant | $1.02 | DIP | 7 | RAIL | TBD | Line 1: $Y (Fairchild logo) &E&Z (Asm. Plant Code) &3 (3-Digit Date Code) Line 2: FSQ510 |
| FSQ510H | Full Production | RoHS Compliant | $1.02 | DIP | 8 | RAIL | TBD | Line 1: $Y (Fairchild logo) &E&Z (Asm. Plant Code) &3 (3-Digit Date Code) Line 2: FSQ510 |
| FSQ510M | Full Production | RoHS Compliant | $1.11 | SOP | 7 | RAIL | TBD | Line 1: $Y (Fairchild logo) &E&Z (Asm. Plant Code) &3 (3-Digit Date Code) Line 2: FSQ510 |
| FSQ510MX | Full Production | RoHS Compliant | $1.11 | SOP | 7 | TAPE REEL | TBD | Line 1: $Y (Fairchild logo) &E&Z (Asm. Plant Code) &3 (3-Digit Date Code) Line 2: FSQ510 |
| * Fairchild 1,000 piece Budgetary Pricing |
| ** A sample button will appear if the part is available through Fairchild's on-line samples program. If there is no sample button, please contact a Fairchild distributor to obtain samples |
Package marking information for product FSQ510 is available. Click here for more information . |
