A43L3616

Voltage on any pin relative to VSS (Vin, Vout )  . . . . . . . . .
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . -1.0V to +4.6V
Voltage on VDD supply relative to VSS (VDD, VDDQ )
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-1.0V to +4.6V
Storage Temperature (TSTG) . . . . . . . . . -55°C to +150°C
Soldering Temperature X Time (TSLODER) . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260°C X 10sec
Power Dissipation (PD) . . . . . . . . . . . . . . . . . . . . . . . . .  1W
Short Circuit Current (Ios) . . . . . .  . . . . . . . . . . . . . .   50mA


The A43L3616 is 134,217,728 bits synchronous high data rate Dynamic RAM organized as 4 X 2,097,152 words by
16 bits, fabricated with AMIC's high performance CMOS technology. Synchronous design  allows precise cycle
control with the use of system clock. I/O transactions are possible on every clock cycle. Range of operating
frequencies, programmable latencies allows the same device A43L3616 to be useful for a variety of high bandwidth, high performance memory system applications.
