THC63LVD104S

The THC63LVD104S receiver is designed to support pixel data transmission between Host and Flat Panel Display from NTSC up to SXGA resolutions. The THC63LVD104S converts the LVDS data streams back into 35bits of CMOS/TTL data with rising edge or falling edge clock for convenient with a variety of LCD panel controllers.At a transmit clock frequency of 112MHz, 30bits of RGB data and 5bits of timing and control data (HSYNC,VSYNC,DE,CNTL1,CNTL2) are transmitted at an effective rate of 784Mbps per LVDS channel.Using a 112MHz clock, the data throughput is 490Mbytes per second.
