TDA8714

· 8-bit resolution
· Sampling rate up to 80 MHz
· No missing codes guaranteed
· High signal-to-noise ratio over a large analog input frequency range (7.7 effective bits at 4.43 MHz full-scale input at f_clk = 80 MHz)
· Overflow/underflow 3-state TTL output
· TTL compatible digital inputs
· Low-level AC clock input signal allowed
· External reference voltage regulator
· Power dissipation only 340 mW (typical)
· Low analog input capacitance, no buffer amplifier required
· No sample-and-hold circuit required.

The TDA8714 is an 8-bit high-speed Analog-to-Digital Converter (ADC) for professional video and other applications. It converts the analog input signal into 8-bit binary-coded digital words at a maximum sampling rate of 80 MHz. All digital inputs and outputs are TTL compatible, although a low-level sine wave clock input signal is allowed.
