Features: . CONTROLLED DRIVING OF THE POWER TRANSISTOR DURING TURN ON AND OFF PHASE FOR MINIMUM POWER DISSIPATION AND HIGH RELIABILITY· HIGH SOURCE AND SINK CURRENT CAPA BILITY·DISCHARGE CURRENT DERIVED FROM PEAK CHARGE CURRENT . CONTROLLED DISCHARGE TIMING · DISABLE FUNCTION FOR SUPPLY UNDER VOLT...
TDA8140: Features: . CONTROLLED DRIVING OF THE POWER TRANSISTOR DURING TURN ON AND OFF PHASE FOR MINIMUM POWER DISSIPATION AND HIGH RELIABILITY· HIGH SOURCE AND SINK CURRENT CAPA BILITY·DISCHARGE CURRENT DER...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Symbol | Parameter |
Value |
Unit |
VCC | DC Supply Voltage |
18 |
V |
Id | Output Current |
Internally Limited |
|
Ptot | Power Dissipation |
Internally Limited |
|
Tstg, Tj | Storage and Junction Temperature |
40, + 150 |
|
Toper | Operating Temperature |
0, + 70 |
