Parameter | Symbol | N-Channel | Unit | |
Drain-Source Voltage | VDS | 30 | V | |
Gate-Source Voltage | VGS | ±12 | ||
Continuous Drain Current (TJ = 150)a | TA = 25 | ID | ±3.4 | A |
TA = 70 | ±2.7 | |||
Pulsed Drain Current | IDM | ±30 | ||
Continuous Source Current (Diode Conduction)a | IS | 1.25 | ||
Maximum Power Dissipationa | TA = 25 | PD | 1 | W |
TA = 70 | 0.64 | |||
Operating Junction and Storage Temperature Range | TJ, Tstg | -55 to 150 | /W |
