LED Display Drivers Low Voltage 16-bit Constant Auto Save
STP16CPS05TTR: LED Display Drivers Low Voltage 16-bit Constant Auto Save
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
ApplicationHIGH CURRENT, HIGH SWITCHING SPEED MOTOR CONTROL, AUDIO AMPLIFIERS DC-DC & DC-AC CO...
Number of Segments : | 16 | Mounting Style : | SMD/SMT | ||
Package / Case : | TSSOP-24 | Operating Supply Voltage : | 3 V to 5.5 V | ||
Maximum Supply Current : | 11.7 mA | Maximum Operating Temperature : | + 125 C | ||
Minimum Operating Temperature : | - 40 C | Packaging : | Reel |
Technical/Catalog Information | STP16CPS05TTR |
Vendor | STMicroelectronics |
Category | Integrated Circuits (ICs) |
Package / Case | 24-TSSOP |
Packaging | Tape & Reel (TR) |
Current - Output / Channel | 100mA |
Number of Outputs | 16 |
Type | Linear (Serial Interface) |
Voltage - Supply | 3 V ~ 5.5 V |
Voltage - Output | 20V |
Topology | Smart |
Frequency | 30MHz |
Operating Temperature | -40°C ~ 125°C |
Efficiency | - |
Drawing Number | * |
Lead Free Status | Lead Free |
RoHS Status | RoHS Compliant |
Other Names | STP16CPS05TTR STP16CPS05TTR 497 6120 2 ND 49761202ND 497-6120-2 |
