M56785FP

· Large power dissipation (Power Package).
·3.3V DSP available.
·The supply voltage with wide range.
·High motor drive current .
· Low saturation voltage. (typical 1.2V at load current 500mA)
·Motor current control for both motor torque directions.
·Reverse torque mode select [SHORT BRAKING,etc].
·Sleep mode. (Zero total current )
·Hall amplifier sensitivity select.(Minimum voltage : 35mVp-p or 50mVp-p)
·FG signal output terminal.
· Automatic stop select. (Removable function)
· Reverse detected signal pin.
