LH28F320BJE-PTTL90

Operating Temperature
    During Read, Block Erase,
    Full Chip Erase, Word/Byte Write
    and Lock-Bit Configuration . . . . . . . . . . . .  0 to +7O(1)
Storage Temperature
    During under Bias . . . . . . . . . . . . . . . . . . . -10 to +8O
    During non Bias . . . . . . . . . . . . . . . . . . . . -65to +125
Voltage On Any Pin
    (except V_CCand V_CC) . . . . . . . . . .  . -0.5V to Vcc+0.5V(2)
    V_CCSupply Voltage . . . . . . . . . . . ..... ... -0.2V to +4.6V(2)
    Vccw Supply Voltage.. ..................... -0.2V to +13.0V(2,3)
Output Short Circuit Current.. .............................. 100mA(4)
NOTES:
I. Operating temperature is for commercial temperature product defined by this specification.
2. All specified voltages are with respect to GND. Minimum DC voltage is -0.5V on input/output pins and -0.2V on Vcc and Vccw pins. During transitions, this level may undershooto -2.OV for periods <20ns. Maximum DC voltage on input/output pins are Vcc+O.5V which, during transitions. may overshoot to Vcc+2.0V for periods <20ns.
3. Maximum DC voltage on Vccw may overshoot to +13.OV for periods <20ns. Applying 12VkO.3V to V_CCduring erase/write can only be done for a maximum of 1000 cycles on each block. V_CC may be connected to 12V&3V for a total of 80 hours maximum.
4. Output shorted for no more than one second. No more than one output shorted at a time.
