HM-6514

•Low Power Standby. . . . . . . . . . . . . . . . . . .125µW Max
•Low Power Operation . . . . . . . . . . . . .35mW/MHz Max
•Data Retention . . . . . . . . . . . . . . . . . . . . . . . at 2.0V Min
•TTL Compatible Input/Output
•Common Data Input/Output
•Three-State Output
•Standard JEDEC Pinout
•Fast Access Time. . . . . . . . . . . . . . . . . .120/200ns Max
•18 Pin Package for High Density
•On-Chip Address Register
•Gated Inputs - No Pull Up or Pull Down Resistors Required

The HM-6514 is a 1024 x 4 static CMOS RAM fabricated using self-aligned silicon gate technology. The device utilizes synchronous circuitry to achieve high performance and low power operation.

On-chip latches are provided for addresses allowing efficient interfacing with microprocessor systems. The data output of HM-6514 can be forced to a high impedance state for use in expanded memory arrays.

Gated inputs allow lower operating current and also elimi- nate the need for pull up or pull down resistors. The HM 6514 is a fully static RAM and may be maintained in any state for an indefinite period of time.Data retention supply voltage and supply current are guaran-teed over temperature.
