FDD5612

MOSFET 60V N-Ch PowerTrench

product image

FDD5612 Picture
See larger image
SeekIC No. : 00156552 Detail

FDD5612: MOSFET 60V N-Ch PowerTrench

FDD5612 Data Sheet

floor Price/Ceiling Price

US $ .19~.23 / Piece | Get Latest Price
Part Number:
FDD5612
Mfg:
Fairchild Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1600
  • 1600~2000
  • 2000~2500
  • 2500~5000
  • Unit Price
  • $.23
  • $.21
  • $.21
  • $.19
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/6/4

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 60 V
Gate-Source Breakdown Voltage : +/- 20 V Continuous Drain Current : 18 A
Resistance Drain-Source RDS (on) : 0.036 Ohms Configuration : Single
Maximum Operating Temperature : + 175 C Mounting Style : SMD/SMT
Package / Case : TO-252AA Packaging : Reel

Description

Transistor Polarity : N-Channel
Gate-Source Breakdown Voltage : +/- 20 V
Configuration : Single
Maximum Operating Temperature : + 175 C
Mounting Style : SMD/SMT
Packaging : Reel
Continuous Drain Current : 18 A
Resistance Drain-Source RDS (on) : 0.036 Ohms
Drain-Source Breakdown Voltage : 60 V
Package / Case : TO-252AA


Parameters:

Technical/Catalog InformationFDD5612
VendorFairchild Semiconductor
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET PolarityN-Channel
Drain to Source Voltage (Vdss)60V
Current - Continuous Drain (Id) @ 25° C5.4A
Rds On (Max) @ Id, Vgs55 mOhm @ 5.4A, 10V
Input Capacitance (Ciss) @ Vds 660pF @ 30V
Power - Max1.6W
PackagingTape & Reel (TR)
Gate Charge (Qg) @ Vgs11nC @ 10V
Package / CaseDPak, SC-63, TO-252 (2 leads+tab)
FET FeatureLogic Level Gate
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names FDD5612
FDD5612
