Am27X010

Storage Temperature OTP Products. . . . . . . . . . . . . .  . . . 65°C to +125°C
Ambient Temperature with Power Applied. . . . . . . . . . . . . 55°C to +125°C
Voltage with Respect to VSS All pins except V_CC . .. . . .0.6 V to V_CC + 0.6 V
V_CC (Note 1). . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .  . . . . . . . .0.6 V to 7.0 V

The Am27X010 is a factory programmed and tested OTP EPROM. It is programmed after packaging prior to final test. Every device is rigorously tested under AC and DC operating conditions to your stable code. It is organized as 128 Kwords by 8 bits per word and is available in plastic dual in-line packages (PDIP), as well as plastic leaded chip carrier (PLCC) packages. ExpressROM devices provide a board-ready memory solution for medium to high volume codes with short leadtimes. This offers manufacturers a cost-effective and flexible alternative to OTP EPROMs and mask programmed ROMs.

Data can be accessed as fast as 55 ns, allowing high-performance microprocessors to operate with reduced WAIT states. Am27X010 offers separate Output Enable (OE#) and Chip Enable (CE#) controls, thus eliminating bus contention in a multiple bus microprocessor system.

AMD's CMOS process technology provides high speed, low power, and high noise immunity. Typical power consumption is only 100 mW in active mode, and 100 W in standby mode.
