AS7C33256NTF36A

Features: .Organization: 262,144 words × 32 or 36 bits. 3.3 core power supply(TM) . NTD architecture for efficient bus operation * 2.5V or 3.3V I/O operation with separate VDDQ.Fast clock to data access: 7.5/8.5/10 ns * 30 mW typical standby power. Fast OE access time: 3.5/4.0 ns * Self-timed writ...

product image

AS7C33256NTF36A Picture
SeekIC No. : 004288533 Detail

AS7C33256NTF36A: Features: .Organization: 262,144 words × 32 or 36 bits. 3.3 core power supply(TM) . NTD architecture for efficient bus operation * 2.5V or 3.3V I/O operation with separate VDDQ.Fast clock to data ac...

floor Price/Ceiling Price

Part Number:
AS7C33256NTF36A
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/24

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

. Organization: 262,144 words × 32 or 36 bits
. 3.3 core power supply(TM)
. NTD architecture for efficient bus operation * 2.5V or 3.3V I/O operation with separate VDDQ
. Fast clock to data access: 7.5/8.5/10 ns * 30 mW typical standby power
. Fast OE access time: 3.5/4.0 ns * Self-timed write cycles
. Fully synchronous operation * Interleaved or linear burst modes
. Flow-through mode * Snooze mode for standby operation
. Asynchronous output enable control
. Available in 100-pin TQFP
. Byte write enables
. Clock enable for operation hold
. Multiple chip enables for easy expansion



Pinout

  Connection Diagram


Specifications

Parameter

Symbol

Min

Max

Unit

Power supply voltage relative to GND

VDD , VDDQ

0.5

+4.6

V

Input voltage relative to GND (input pins)

VIN

0.5

VDD + 0.5

V

Input voltage relative to GND (I/O pins)

VIN

0.5

VDDQ+ 0.5

V

Power dissipation

PD

1.8

W

DC output current

IOUT

50

mA

Storage temperature (plastic)

Tstg

65

+150

oC

Temperature under bias (Junction)

Tbias

65

+150

oC
