A43L8316

Voltage on any pin relative to VSS (Vin, Vout )  . . . . . . . . .
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . -1.0V to +4.6V
Voltage on VDD supply relative to VSS (VDD, VDDQ )
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-1.0V to +4.6V
Storage Temperature (TSTG) . . . . . . . . . -55°C to +150°C
Soldering Temperature X Time (TSLODER) . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260°C X 10sec
Power Dissipation (PD) . . . . . . . . . . . . . . . . . . . . . . . . . 1W
Short Circuit Current (Ios) . . . . . .  . . . . . . . . . . . . . .  50mA

The A43L8316 is 4,194,304 bits synchronous high data rate Dynamic RAM organized as 2 X 131,072 words by 16 bits, fabricated with AMIC's high performance CMOS technology. Synchronous design allows precise cycle control with the use of system clock. I/O transactions are possible on every clock cycle. Range of operating frequencies, programmable latencies allows the same device to be useful for a variety of high bandwidth, high performance memory system applications.
