Kyocera KZ820 phone cable circuit diagram

Published:2011/8/3 2:01:00 Author:Ecco | Keyword: Kyocera phone cable circuit diagram

Kyocera KZ820 phone cable circuit diagram
  (View)

View full Circuit Diagram | Comments | Reading(684)

TV_TRANSMITTER_1

Published:2009/7/8 20:58:00 Author:May

TV_TRANSMITTER_1
The video-link transmitter accepts color and B/W video, and audio inputs from VCRs, camcorders, small TV cameras, and microphones. The unit runs on a nominal 12 Vdc and draws 100 mA in the lowpower version, or 500 mA in the 2-W version. The kit is available from North Country Radio, P.O. Box 53, Wykagyl Station, NY 10804.   (View)

View full Circuit Diagram | Comments | Reading(3240)

Hisense 628 phone cable circuit diagram

Published:2011/8/2 22:45:00 Author:Ecco | Keyword: Hisense, phone cable

Hisense 628 phone cable circuit diagram
  (View)

View full Circuit Diagram | Comments | Reading(670)

Haier To WenXing 1000 mobile cable schematic diagram

Published:2011/8/3 2:25:00 Author:Ecco | Keyword: Haier , To WenXing 1000, mobile cable

Haier To WenXing 1000 mobile cable schematic diagram
  (View)

View full Circuit Diagram | Comments | Reading(640)

AUTOMATIC_BLOOD

Published:2009/7/20 20:52:00 Author:Jessie

AUTOMATIC_BLOOD
High-gail amplifier-microphone combination detects pulse beats and feeds them through shaper circuit to hold-relays that lock pressure gages at systolic and diastolic blood-pressure readings.-R. J. Roy and M. Weiss, Inexpensive Monitor Reads Blood Pressure Automatically, Electronics, 35:47, p 40-41.   (View)

View full Circuit Diagram | Comments | Reading(767)

TV_SOUND_SLOPE_DETECTOR

Published:2009/7/20 20:52:00 Author:Jessie

TV_SOUND_SLOPE_DETECTOR
Uses drift transistor as efficient, highly sensitive oscillating linear-slope detector, injection-locked by one stage sound driver. A-m rejection is uniformly high over full detector bandwidth. Audio output is constant, independent of carrier strength.-M. Meth, Tv Sound Detector Uses Drift Transistor, Electronics, 32:8, p 62-64.   (View)

View full Circuit Diagram | Comments | Reading(943)

TELEPRINTER_CONTROL

Published:2009/7/20 20:51:00 Author:Jessie

TELEPRINTER_CONTROL
Coded pulse train controls teleprinter. When negative pulses are applied to grid of V2, line relays open in correspondence to pulse pattern.-R. L. Thomas, R. Howat, and N. H. Mackworth, Tv Tracker Records Eye Focus Points, Electronics, 33:17, p 57-59.   (View)

View full Circuit Diagram | Comments | Reading(700)

DELTA_TV_SOUND

Published:2009/7/20 20:51:00 Author:Jessie

DELTA_TV_SOUND
Costs less than ratio derector sound system. Uses discriminator circuit with triode operating us power detector, with cancellation of undesired aim fundamental.-R. B. Dome, Inexpensive Sound for Television Receivers, Electronics, 32:9, p 66-68.   (View)

View full Circuit Diagram | Comments | Reading(764)

TUNED_PLATE_TRIODE_POWER_OSCILLATOR

Published:2009/7/20 20:51:00 Author:Jessie

TUNED_PLATE_TRIODE_POWER_OSCILLATOR
Drives ultrasonic transducer at odd harmonically related frequencies in 900 kc to 5 Mc optimum range, for neurosurgery, al power levels within 1 db of any prescribed level between 0.05 and 100 acoustic walls, without correction of amplitude after radiation has begun.-B. J. Cosman and T. F.Hueler, Instrumentation for Ultrasonic Neuro-surgery, Electronics, 32:200, p 53-57.   (View)

View full Circuit Diagram | Comments | Reading(657)

OUTLINE_GENERATOR_FOR_TV_STUDIO

Published:2009/7/20 20:50:00 Author:Jessie

OUTLINE_GENERATOR_FOR_TV_STUDIO
Produces variable-size rectangles in any desired position on tv screen, including horizontal or vertical white lines, for emphasizing particular part of picture during educational tv broadcast.-G. Southworth, Outline Generator for Educational Television, Electronics, 32:14, p 52-53.   (View)

View full Circuit Diagram | Comments | Reading(668)

IRON_LUNG_AIR_INTAKE_CONTROL

Published:2009/7/20 21:03:00 Author:Jessie

IRON_LUNG_AIR_INTAKE_CONTROL
Air exhaled by patient is sampled and analyzed for carbon dioxide concentration by commercial infrared analyzer that provides electrical output proportional to amount of carbon dioxide. Analyzer output charges C2 to level dependent on carbon dioxide concentration. Comparison circuit controls relays K2 and K3 so iron lung bleeder valve keeps concentration within preset limits. V5, V6, and K2 establish upper limitV7, other half of V6, and K3 establish lower limit.-Control Regulates Iron Lung, Electronics, 31:41, p 108.   (View)

View full Circuit Diagram | Comments | Reading(921)

EEG_TELEMETER

Published:2009/7/20 21:01:00 Author:Jessie

EEG_TELEMETER
Amplifier, modulator, and oscillator produce 37.7-Mc signals frequency-modulated by scalp voltages of epileptics. Radiated signal may be picked up by antenna of receiver at distances up to 40 feet from patient in observation room.-C. L. Yeager and J. Henderson, Jr., Unit Telemeters Scalp Voltages, Electronics, 31:29, p 86.   (View)

View full Circuit Diagram | Comments | Reading(816)

EMITTER_FEEDBACK_PEAKING_GIVES_100_MC_BANDWIDTH

Published:2009/7/20 21:01:00 Author:Jessie

EMITTER_FEEDBACK_PEAKING_GIVES_100_MC_BANDWIDTH
EMITTER_FEEDBACK_PEAKING_GIVES_100_MC_BANDWIDTH

Four identical AF102 stages amplify pulse output of delta modulator in tv waveguide link.-C. Kramer and J. C. Balder, Delta-Modulated Television Waveguide Link, Electronics, 36:31, p 50-52.   (View)

View full Circuit Diagram | Comments | Reading(632)

ESSURE_SENSITIVE_RESISTOR_CONTROLSARTIFICIAL_HAND

Published:2009/7/20 21:00:00 Author:Jessie

ESSURE_SENSITIVE_RESISTOR_CONTROLSARTIFICIAL_HAND
Control binary Q6-07 is triggered on through diode AAZ18 and reset by Q8 whose conduction threshold is determined by R1. Settings of R1, R2, and RC control closing of artificial hand and strength of grip. Servo amplifier drives motor in hand and follow-up potentiometer.-G. W.Horn, Muscle Voltage Moves Artificial Hand, Electronics, 36:41, p 34-36.   (View)

View full Circuit Diagram | Comments | Reading(1983)

FOUR_TRANSISTOR_T_U_N_E_R

Published:2009/7/20 21:00:00 Author:Jessie

FOUR_TRANSISTOR_T_U_N_E_R
Diffused-base mesa transistors permit design of tv tuners with noise performance equal to that of tube tuners. Article gives complete design procedure for r-f amplifier, mixer, and oscillator stages.-H. F. Cooke, Designing Tv Tuners with Mesa Transistors, Electronics, 33:15, p 64-69.   (View)

View full Circuit Diagram | Comments | Reading(1002)

CCTV_10_MC_CARRIER_TRANSMITTER_TERMINAL

Published:2009/7/20 20:59:00 Author:Jessie

CCTV_10_MC_CARRIER_TRANSMITTER_TERMINAL
Uses single tetrode transistor in oscillator to feed four-diode balanced modulator. Peak level of modulator output is 4 db below 1 mw.-L. G. Schimpf, Carrier Transmission for Closed-Circuit Television, Electronics, 32:24, p 66-68.   (View)

View full Circuit Diagram | Comments | Reading(623)

ANESTHESIA_CONTROL

Published:2009/7/20 20:59:00 Author:Jessie

ANESTHESIA_CONTROL
Drives anesthetic pump servomotor in response to signals from electroencephalograph that continuously monitors border of wakefulness of patient undergoing surgical operation Anesthetic is supplied at fixed level, proportion to cortical activity of brain,-How Electronics Controls Depth of Anesthesia Electronics, 32;5,p 43-45.   (View)

View full Circuit Diagram | Comments | Reading(783)

CCTV_REPEATER_POWER_SUPPLY

Published:2009/7/20 20:59:00 Author:Jessie

CCTV_REPEATER_POWER_SUPPLY
CCTV REPEATER POWER SUPPLY-Operates from 24.v battery at transmitting terminal. C1 isolates battery voltage from terminal equipment, and L1 prevents shorting of signal. Two 7-v zener diodes in series serve as voltage regulators.-L. G. Schimpf, Carrier Transmission for Closed-Circuit Television, Electronics, 32:24, p 66-68.   (View)

View full Circuit Diagram | Comments | Reading(1408)

HORIZONTAL_DEFLECTION_1

Published:2009/7/20 20:58:00 Author:Jessie

HORIZONTAL_DEFLECTION_1
Two-transistor circuit provides high ratio of reverse to for. ward base drive. Oscillator current is 0.12 amp, output-stage current 0.72 amp, und push-pull yoke current is 11 amp.-M. Fischman, Transistorized Horizontal Deflection for Television, Electronics, 32:33, p 60-63.   (View)

View full Circuit Diagram | Comments | Reading(1144)

HEART_PACER

Published:2009/7/20 21:12:00 Author:Jessie

HEART_PACER
Supplies pulses that drive heart at desired rate. Output is connected to heart muscles by small wires. Frequency of relaxation oscillator is controlled, between 50, and 200 ppm, by R2.-L. D. Trump and R. L. Skinner, Simple Heart Pacer is Highly Reliable, Electronics, 32:39, p 92-93.   (View)

View full Circuit Diagram | Comments | Reading(710)
