VAT1-S24-D15-SMT, VAT1-S24-D5-SMT, VAT1-S5-D12-SMT

Table of contents:
Info of VAT1-S24-D15-SMT
Info of VAT1-S24-D5-SMT
Info of VAT1-S5-D12-SMT

VAT1-S24-D15-SMT, VAT1-S24-D5-SMT, VAT1-S5-D12-SMT Selling Leads, Datasheet

MFG:CUI Inc (VA) Category:Power Supplies D/C:08+/09+

VAT1-S24-D15-SMT, VAT1-S24-D5-SMT, VAT1-S5-D12-SMT Datasheet download

Five Points

Part Number: VAT1-S24-D15-SMT

Category: Power Supplies

MFG: CUI Inc (VA)

Package Cooled:

D/C: 08+/09+

Description: CONVERTER DC/DC +/-12V OUT 1W

Price Break

1
10
25
50
100

Unit Price

5.56000
5.14300
5.00400
4.86500
4.58700

Extended Price

5.56
51.43
125.10
243.25
458.70

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

VAT1-S24-D15-SMT Parameters

Technical/Catalog Information	VAT1-S24-D15-SMT
Vendor	CUI Inc (VA)
Category	Power Supplies
Voltage - Input	21.6 ~ 26.4V
Output	±15V
Power (Watts)	1W
Number of Outputs	2
1st Output	15 VDC @ 33mA
2nd Output	-15 VDC @ 33mA
3rd Output	-
4th Output	-
Type	Isolated
Mounting Type	Surface Mount
Packaging	Cut Tape (CT)
Package / Case	10-DIP Module
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	VAT1 S24 D15 SMT VAT1S24D15SMT 102 1393 1 ND 10213931ND 102-1393-1

VAT1-S24-D5-SMT Parameters

Technical/Catalog Information	VAT1-S24-D5-SMT
Vendor	CUI Inc
Category	Power Supplies
Voltage - Input	21.6 ~ 26.4V
Output	±5V
Power (Watts)	1W
Number of Outputs	2
1st Output	5 VDC @ 100mA
2nd Output	-5 VDC @ 100mA
3rd Output	-
4th Output	-
Type	Isolated
Mounting Type	Surface Mount
Packaging	Tape & Reel (TR)
Package / Case	10-DIP Module
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	VAT1 S24 D5 SMT VAT1S24D5SMT 102 1391 2 ND 10213912ND 102-1391-2

VAT1-S5-D12-SMT Parameters

Technical/Catalog Information	VAT1-S5-D12-SMT
Vendor	CUI Inc (VA)
Category	Power Supplies
Voltage - Input	4.5 ~ 5.5V
Output	±12V
Power (Watts)	1W
Number of Outputs	2
1st Output	12 VDC @ 42mA
2nd Output	-12 VDC @ 42mA
3rd Output	-
4th Output	-
Type	Isolated
Mounting Type	Surface Mount
Packaging	Cut Tape (CT)
Package / Case	10-DIP Module
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	VAT1 S5 D12 SMT VAT1S5D12SMT 102 1386 1 ND 10213861ND 102-1386-1
