MFG:Littelfuse / Teccor Brand Thyristors Category:Discrete Semiconductor Products Package Cooled:TO-251 D/C:07+
S8008V, S8010D, S8010L Datasheet download
Category: Discrete Semiconductor Products
MFG: Littelfuse / Teccor Brand Thyristors
Package Cooled: TO-251
D/C: 07+
Description: SCR ISOLATED 800V 10A TO-220AB
Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.
TOP
PDF/DataSheet Download
Datasheet: S8008V
File Size: 227799 KB
Manufacturer: LITTELFUSE [Littelfuse]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: S8010D
File Size: 227799 KB
Manufacturer: LITTELFUSE [Littelfuse]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: S8010L
File Size: 227799 KB
Manufacturer: LITTELFUSE [Littelfuse]
Download : Click here to Download
| Technical/Catalog Information | S8008V |
| Vendor | Littelfuse / Teccor Brand Thyristors |
| Category | Discrete Semiconductor Products |
| SCR Type | Standard Recovery |
| Voltage - Off State | 800V |
| Current - On State (It (RMS) (Max) | 8A |
| Current - On State (It (AV)) (Max) | 5.1A |
| Current - Gate Trigger (Igt) (Max) | 15mA |
| Current - Hold (Ih) (Max) | 30mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 83A, 100A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5V |
| Mounting Type | Through Hole |
| Package / Case | IPak, TO-251, DPak, VPak (3 straight leads + tab) |
| Packaging | Bulk |
| Drawing Number | * |
| Lead Free Status | Request Inventory Verification |
| RoHS Status | Request Inventory Verification |
| Other Names | S8008V S8008V |
| Technical/Catalog Information | S8010L |
| Vendor | Littelfuse / Teccor Brand Thyristors |
| Category | Discrete Semiconductor Products |
| SCR Type | Standard Recovery |
| Voltage - Off State | 800V |
| Current - On State (It (RMS) (Max) | 10A |
| Current - On State (It (AV)) (Max) | 6.4A |
| Current - Gate Trigger (Igt) (Max) | 15mA |
| Current - Hold (Ih) (Max) | 30mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 83A, 100A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5V |
| Mounting Type | Through Hole |
| Package / Case | TO-220 |
| Packaging | Bulk |
| Drawing Number | * |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | S8010L S8010L |
The Teccor line of thyristor SCR semi-conductors are half-wave,unidirectional, gate-controlled rectifiers which complement Teccor's line of sensitive SCRs. Teccor offers devices with ratings of 1 A to 70 A and 200 V to 1000 V, with gate sensitivities from 10 mA to 50 mA. If gate currents in the 12 A to 500 A ranges are required, see "Sensitive SCRs" section of this catalog.
Three packages are offered in electrically isolated construction where the case or tab is internally isolated to allow the use of low-cost assembly and convenient packaging techniques.
The Teccor line of SCRs features glass-passivated junctions to ensure long-term reliability and parameter stability. Teccor's glass offers a rugged, reliable barrier against junction contamination.
Variations of devices covered in this data sheet are available for custom design applications. Consult the factory for more information.
