MPX2050GP, MPX2050GSX, MPX2100A

Table of contents:
Info of MPX2050GP
Info of MPX2050GSX
Info of MPX2100A

MPX2050GP, MPX2050GSX, MPX2100A Selling Leads, Datasheet

MFG:Freescale Semiconductor Category:Sensors, Transducers D/C:02+

MPX2050GP, MPX2050GSX, MPX2100A Datasheet download

Five Points

Part Number: MPX2050GP

Category: Sensors, Transducers

MFG: Freescale Semiconductor

Package Cooled:

D/C: 02+

Description: SENSOR ABS PRESS 14.5PSI MAX

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

MPX2050GP Parameters

Technical/Catalog Information	MPX2050GP
Vendor	Freescale Semiconductor
Category	Sensors, Transducers
Operating Pressure	0 ~ 7.25 PSI
Voltage - Rated	10VDC
Output	0 ~ 40mV
Package / Case	4-SIP
Pressure Type	Gauge
Features	Ratiometric Output
Interface	PC Board Mount
Pressure Port	Male
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MPX2050GP MPX2050GP

MPX2050GP General Description

The MPX2050 series device is a silicon piezoresistive pressure sensors providing a highly accurate and linear voltage output - directly proportional to the applied pressure. The sensor is a single, monolithic silicon diaphragm with the strain gauge and a thinfilm resistor network integrated onchip. The chip is laser trimmed for precise span and offset calibration and temperature compensation.

MPX2050GP Maximum Ratings

Parametrics	Symbol	Value	Unit
Maximum Pressure(P1 > P2)	P_max	200	kPa
Storage Temperature	T_stg	40 to +125	°C
Operating Temperature	T_A	40 to +125	°C

NOTE: Exposure beyond the specified limits may cause permanent damage or degradation to the device.

MPX2050GP Features

• Temperature Compensated Over 0°C to +85°C
• Unique Silicon Shear Stress Strain Gauge
• Easy to Use Chip Carrier Package Options
• Ratiometric to Supply Voltage
• Differential and Gauge Options
• ±0.25% Linearity (MPX2050)

MPX2050GP Typical Application

• Pump/Motor Controllers
• Robotics
• Level Indicators
• Medical Diagnostics
• Pressure Switching
• NonInvasive Blood Pressure Measurement

MPX2050GSX General Description

MPX2050GSX Maximum Ratings

Parametrics	Symbol	Value	Unit
Maximum Pressure(P1 > P2)	P_max	200	kPa
Storage Temperature	T_stg	40 to +125	°C
Operating Temperature	T_A	40 to +125	°C

NOTE: Exposure beyond the specified limits may cause permanent damage or degradation to the device.

MPX2050GSX Features

MPX2050GSX Typical Application

• Pump/Motor Controllers
• Robotics
• Level Indicators
• Medical Diagnostics
• Pressure Switching
• NonInvasive Blood Pressure Measurement

MPX2100A Parameters

Technical/Catalog Information	MPX2100A
Vendor	Freescale Semiconductor
Category	Sensors, Transducers
Operating Pressure	0 ~ 14.5 PSI
Voltage - Rated	10VDC
Output	0 ~ 40mV
Package / Case	4-SIP
Pressure Type	Absolute
Features	Ratiometric Output
Interface	PC Board Mount
Pressure Port	Open
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MPX2100A MPX2100A
