BD03AV, BD04, BD05

Table of contents:
Info of BD03AV
Info of BD04
Info of BD05

BD03AV, BD04, BD05 Selling Leads, Datasheet

MFG:C&K Components Category:Switches Package Cooled:NEW AND ORIGINAL D/C:08+/09+

BD03AV, BD04, BD05 Datasheet download

Five Points

Part Number: BD03AV

Category: Switches

MFG: C&K Components

Package Cooled: NEW AND ORIGINAL

D/C: 08+/09+

Description: SWITCH DIP TOP SLIDE 5POS

Price Break

1
25
100
250
500
1000

Unit Price

2.81000
2.24640
1.77840
1.40400
1.31040
1.21680

Extended Price

2.81
56.16
177.84
351.00
655.20
1216.80

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

BD03AV Parameters

Technical/Catalog Information	BD03AV
Vendor	C&K Components
Category	Switches
Actuator Type	Standard
Orientation	Side Actuated
Number of Positions	3
Circuit	SPST
Actuator Level	Raised
Mounting Type	Through Hole
Contact Rating @ Voltage	0.1A @ 5VDC
Washable	Yes
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	BD03AV BD03AV CKN3012 ND CKN3012ND CKN3012

BD04 Parameters

Technical/Catalog Information	BD04
Vendor	C&K Components
Category	Switches
Actuator Type	Standard
Orientation	Top Actuated
Number of Positions	4
Circuit	SPST
Actuator Level	Raised
Mounting Type	Through Hole
Contact Rating @ Voltage	0.1A @ 5VDC
Washable	Yes
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	BD04 BD04 CKN3003 ND CKN3003ND CKN3003

BD05 Parameters

Technical/Catalog Information	BD05
Vendor	C&K Components
Category	Switches
Actuator Type	Standard
Orientation	Top Actuated
Number of Positions	5
Circuit	SPST
Actuator Level	Raised
Mounting Type	Through Hole
Contact Rating @ Voltage	0.1A @ 5VDC
Washable	Yes
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	BD05 BD05 CKN3004 ND CKN3004ND CKN3004
