XE5620G

· Small Size: The HyPLCC™ measures less than 1 inch by 1 inch square and 0.350 inches thick
· Surface-mountable: The HyPLCC™ package is equivalent to a 68-Pin PLCC device.
· Data transfer at all rates from 300 BPS to 56 KBPS using V.90, V.34bis, V.34, V.32bis, V.32, V.22bis, V.22, V.23, V.21, Bell 212A, and Bell 103 Protocols
· Modem Control and Configuration via industry standard AT Commands.
· Nonvolatile memory stores modem configuration and permits stored number dialing.
· Incorporates Fax send and receive capabilities controlled by Class 1 Fax commands.
· Complete integrated DAA includes, Ring Detect, Loop Current Holding Circuit, Hook Switch. Metallic Surge Protection, and Solid-State DAA
· User Transferrable FCC Part 68 Registration (pending)
· Compliant with telecom requirements around the world.
· UL60950 Recognition (pending)
· Low Power operation, 3.3 Volts, 300 milliwatt;

Xecom's XE5620G simplifies integration of dial-up communications into embedded systems. It offers a single modem solution for use throughout the world, and its PLCC package allows the XE5620G to fit in the tightest system layout. It is a breakthrough for the embedded system designer.

The XE5620G offers unprecidented design flexibility.

It offers a common communications solution for countries around the world, and the Hybrid PLCC package (HyPLCC™) is both the smallest complete modem and the only surface mount modem you can buy. The XE5620G fits a 68-Pin PLCC socket and therefore can be mounted in a socket or soldered onto the board. As the world's smallest complete modem, you can place the XE5620G where no other modem will fit.

The surface mount package and small size of the XE5620G are particularly impressive when you realize it is a complete modem. The DAA, RAM, ROM, Crystal; everything is included. The XE5620G even includes transferrable FCC Part 68 Registration. No further testing is required for US applications
