XE3314C

• Meets telecom requirements for Europe, North America, and Japan: Includes User Transferrable FCC Part 68 Registration and CTR21 compliance
• Small Size: 2.75 inches by 1.38 inches by 0.42 inches;
• Modem Protocols for data transmission from 33.6 KBPS down to 300 BPS: V.34bis, V.34, V.32bis, V.32, V.22bis, V.22, V.21, Bell 212A and 103;
• Modem Control and Configuration via standard AT Commands
• Fax Protocols: V.17, V.29, V.27ter, and V.21 channel 2
• Error Correction; V.42, MNP2-4 and MNP10
• Data Compression; V.42bis and MNP5 provides a maximum effective data rate of 133,400 bps.
• Non-Volatile Memory included for storing telephone numbers and modem configuration.
• Standard operating temperature range 0C to 70C. Extended operating temperature range of -40C to +85C is available

Xecom's XE3314C is a complete, 33.6 Kbps modem in a single component. Xecom designed the XE3314C for use throughout North America, Europe and Japan. It includes user transferrable FCC Part 68 Registration for direct connection to telephone lines in the United States and is compliant with CTR21, the standard for pan-European telecommunications approval.

The XE3314C is a complete modem packaged in a compact module. The XE3314C includes all required modem circuits including the DAA. XE3314C users do not need to add RAM, ROM, Crystals, low distortion transformer, or switches to complete the modem design.

The user only needs to provide the TTL level, serial interface and the telephone line connection.

The XE3314C is pin compatible with Xecom's XE1414C, and XE5614C modems. This family of modems permits a simple upgrade path from 14,400 bps to 56,000 bps for international embedded modem applications.
