U4256BM

` Reference oscillator up to 15 MHz (tuned)
` Oscillator buffer output (for AM up/down conversion)
` Two programmable 16-bit dividers
` Fine-tuning steps: AM 1 kHz, FM 2 kHz
` Fast response time due to integrated loop push-pull stage
` 3-wire bus (enable, clock and data; 3 V and 5 V microcontrollers acceptable)
` Four programmable switching outputs (open drain)
` Three DACs for software controlled tuner alignment
` Low power consumption
` High S/N ratio
` Integrated band gap - only one supply voltage necessary

The U4256BM is a single chip frequency synthesizer in BICMOS technology. Together with the AM/FM IC U4255BM, it performs a complete AM/FM car radio front end, which is recommended also for RDS (Radio Data System) applications. U4256BM is controlled by 3-wire bus and contains also Digital to Analog Converters (DACs) for automatic alignment of the AM/FM tuner.
