U2762B

· Single-conversion receiver with 10.7-MHz IF
· Comparator for bit slicer integrated
· Temperature-compensated RSSI with 65 dB dynamic range
· Supply-voltage range 2.7 V to 3.3 V
· Only 17 mA typical current consumption
· Few external components
· SSO28 package

The receiver IC U2762B-B is specifically designed for cordless telephone applications in the 900-MHz ISM band. It is manufactured using TEMIC's advanced UHF process. The IC consists of a 900-MHz RF amplifier and mixer, 10.7-MHz IF amplifier, limiter, RSSI, quadrature demodulator and comparator for the bit-slicer function. The U2762B-B features 2.9-V operation. In conjunction with TEMIC's transmitter IC U2763B-B and the PLL U2781B, a complete ISM RF IC kit is available which fits perfectly with AMD's PhoX controllers AM79C432A and AM79C433.
