TMS320F206

Supply voltage range, VDD (see Note 1). . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3 V to 7 V
Input voltage range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . .  . 0.3 V to 7 V
Output voltage range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . . 0.3 V to 7 V
Operating free-air temperature range, TA(TMS320F206PZ) . . . . . . . . . . . . .0°C to 70°C
                                                              (TMS320F206PZA) . . . . . . . . .  . 40°C to 85°C
Storage temperature range, Tstg  . . . . . . . . . . . . . . . . . . . . . . . . . . .  55°C to 150°C

The TMS320F206 Texas Instruments (TI) digital signal processor (DSP) is fabricated with static CMOSintegrated-circuit technology, and the architectural design is based upon that of the TMS320C20x series,optimized for low-power operation. The combination of advanced Harvard architecture, on-chip peripherals,on-chip memory, and a highly specialized instruction set is the basis of the operational flexibility and speed ofthe 'F206.

The 'F206 offers these advantages:

. 32K
.  16 words on-chip flash EEPROM reduces system cost and facilitates prototyping
. Enhanced TMS320 architectural design for increased performance and versatility
. Advanced integrated-circuit processing technology for increased performance
. 'F206 devices are pin- and code-compatible with 'C203 devices.
. Source code for the 'F206 DSP is software-compatible with the 'C1x and 'C2x DSPs and is upwardlycompatible with fifth-generation DSPs ('C5x)
. New static-design techniques for minimizing power consumption and increasing radiation tolerance
