Product Details

Description



Features:

 Organization
   TM497FBK32H/I: 4 194 304 x 32
   TM893GBK32H/I: 8 388 608 x 32
 Single 5-V Power Supply (±10% Tolerance)
 72-Pin Single In-Line Memory Module (SIMM) for Use With Socket
 TM497FBK32H/I Uses Eight 16M-Bit Dynamic Random-Access Memories (DRAMs) in Plastic Small-Outline J-Lead (SOJ) Packages
 TM893GBK32H/I Uses Sixteen 16M-Bit DRAMs in Plastic SOJ Packages
 Long Refresh Period . . . 32 ms (2048 Cycles)
 All Inputs, Outputs, Clocks Fully TTL-Compatible
 3-State Output
 Common CAS Control for Nine Common Data-In and Data-Out Lines in Four Blocks
 Enhanced Page-Mode Operation With CAS-Before-RAS (CBR), RAS-Only, and Hidden Refresh
 Presence Detect
Performance Ranges:
                                   ACCESS    ACCESS     ACCESS    READ
                                      TIME        TIME           TIME        OR
                                       tRAC        tAA             tCAC    WRITE
                                                                        CYCLE
                                       (MAX)     (MAX)         (MAX)      (MIN)
'497FBK32H/I-50          50 ns     25 ns          13 ns     20 ns
'497FBK32H/I-60          60 ns     30 ns          15 ns     25 ns
'497FBK32H/I-70          70 ns     35 ns          18 ns     30 ns
'497GBK32H/I-50          50 ns     25 ns          13 ns     20 ns
'497GBK32H/I-60          60 ns     30 ns          15 ns     25 ns
'497GBK32H/I-70          70 ns     35 ns          18 ns     30 ns
 Low Power Dissipation
 Operating Free-Air Temperature Range 0°C to 70°C
 Gold-Tabbed Version Available:† TM497FBK32H, TM893GBK32H
Tin-Lead (Solder-) Tabbed Version Available: TM497FBK32I, TM893GBK32I


Pinout

Connection Diagram


Specifications

Supply voltage range, VCC (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . .  1 V to 7 V
Voltage range on any pin (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  1 V to 7 V
Short-circuit output current  . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 mA
Power dissipation . . . . . . . . . . . . . . . . . . . . . . .  . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 W
Operating free-air temperature range, TA  . . . . . . . . . .  . . . . . . . . . . . . . . . .0°C to 70°C
Storage temperature range, Tstg  . . . . . . . . . . .  . . . . . . . . . . . . . . . . . . .55°C to 125°C


Description

The TM497FBK32I is a 16M-byte dynamic random-access memory (DRAM) module organized as four times 4194304 × 8 bits in a 72-pin leadless single-in line memory module (SIMM). The SIMM is composed of eight TMS417409ADJ DRAMs, each in 24/26-lead plastic small-outline J-lead (SOJ) packages mounted on a substrate with decoupling capacitors. The TMS417409ADJ is described in the TMS416409A, TMS417409A data sheet (literature number SMKS893).

The TM497FBK32I SIMM is available in the single-sided BK leadless module for use with sockets. The TM497FBK32H/I features RAS access times of 50, 60, and 70 ns. This device is characterized for operation from 0°C to 70°C.

The TM497FBK32I is a 32M-byte DRAM organized as four times 8388608 × 8 bits in a 72-pin leadless SIMM. The SIMM is composed of sixteen TMS417409ADJ DRAMs.

The TM497FBK32I SIMM is available in the double-sided BK leadless module for use with sockets. The TM893GBK32H/I features RAS access times of 50, 60, and 70 ns. This device is characterized for operation from 0°C to 70°C.
