THS9001

 ` High Dynamic Range
 ` OIP₃ = 36 dBm
 ` NF < 4.5 dB
 ` Single Supply Voltage
 ` High Speed
` V_S = 3 V to 5 V
` I<sub>S</sub> = Adjustable
` Input / Output Impedance
` 50 W

` IF Amplifier
` TDMA: GSM, IS-136, EDGE/UWE-136
` CDMA: IS-95, UMTS, CDMA2000
` Wireless Local Loop
` Wireless LAN: IEEE802.11

The THS9001 is a medium power, cascadeable, gain block optimized for high IF frequencies. The amplifier incorporates internal impedance matching to 50 W and achieves greater than 15-dB input and output return loss from 50 MHz to 350 MHz with V_S = 5 V, R_(BIAS) = 237 W, L_(COL) = 470 nH. THS9001 is designed requires only 2 dc-blocking capacitors, 1 power-supply bypass capacitor, 1 RF choke, and 1 bias resistor.
