TH8082

 Single wire LIN transceiver
 Compatible to LIN Protocol Specification, Rev. 1.1
 Compatible to ISO9141 functions
 Control Output for voltage regulator
 Up to 20 kbps bus speed
 Low RFI due to slew rate control
 Fully integrated receiver filter
 Protection against load dump, jump start
 Bus terminals proof against short-circuits and transients in the automotive environment
 Very low (25 A) typical power consumption in sleep mode
 Thermal overload and short circuit protection
 High impendance Bus pin in case of loss of ground and undervoltage condition
 ± 4kV ESD protection on bus pin

The TH8082 is a physical layer device for a single wire data link capable of operating in applications where high data rate is not required and a lower data rate can achieve cost reductions in both the physical media components and in the microprocessor which use the network.The TH8082 is designed in accordance to the physical layer definition of the LIN Protocol Specification, Rev. 1.2 . The IC furthermore can be used in ISO9141 systems.

Because of the very low current consumption of the TH8082 in the recessive state it's particularly suitable for ECU applications with hard standby current requirements.An advanced sleep mode capability allows a shutdown of the whole application . The included wake-up function detects incoming dominant bus messages and enables the voltage regulator.
