TFP420

The TFP420 is a PanelBusE flat panel display product, part of a comprehensive family of end-to-end DVI 1.0 compliant solutions. Targeted primarily at desktop and notebook PCs, the TFP420 finds applications in any design requiring a high-speed digital interface with connectivity to the IntelE DVO port.

The scalable (1.1 V to 1.8 V) low-swing digital pixel interface provides a low-EMI and high-speed bus that connects seamlessly with Intel's digital video out (DVO) port, perfectly linking the graphics controller and the DVI transmitter. The DVI interface supports display resolutions up to UXGA at 165 MHz in 24-bit true color pixel format.

The TFP420 combines PanelBusE circuit innovation, TI's advanced 0.18 mm EPIC-5E CMOS process technology, and PowerPADE ultralow ground inductance package technology to provide a reliable, low-power, and low-noise digital interface solution.
