The TD62101F is designed as high voltage and high current darlington drivers comprised of seven NPN darlington pairs.
TD62101F has four features. (1)Output current single output would be max 500mA. (2)High sustaining voltage output would be min 25V. (3)Inputs compatible with various types of logic. (4)Package type would be SOP 16 pin. Those are all the main features.
Some absolute maximum ratings TD62101F have been concluded into several points as follow. (1)Its output sustaining voltage would be from -0.5V to 25V. (2)Its output current would be 500mA/ch. (3)Its input voltage would be from -0.5V to 30V. (4)Its input current would be 25mA. (5)Its power dissipation would be 0.625W. (6)Its operating temperature range would be from -40°C to 85°C. (7)Its storage temperature range would be from -55°C to 150°C. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device.
Also some electrical characteristics TD62101F are concluded as follow. (1)Its output leakage current would be max 100uA. (2)Its collector to emitter saturation voltage would be typ 1.3V and max 2.2V at Iout=350mA and Iin=600uA and would be typ 1.1V and max 2.0V at Iout=200mA and Iin=400uA and it would be typ 1.0V and max 1.8V at Iout=100mA and Iin=200uA. (3)Its DC current transfer ratio would be min 1000 with test conditions of Vce=2V and Iout=350mA. (4)Its input current would be typ 0.25mA for output on and would be min 50uA and typ 65uA for output off. (5)input capacitance would be typ 15pF with test conditions of Vin=0 and f=1MHz. (6)Its turn-on delay would be typ 0.1us with test conditions of Vout=25V and RL=70ohms and CL=15pF. (7)Its turn-off delay would be typ 0.2us with test conditions of Vout=25V and RL=70ohms and CL=15pF. If you have any question or suggestion or want to know more information please contact us for TD62101F details. Thank you!
