TC58DVM72A1FT00

The TC58DVM72A1FT00 is a 128-Mbit (138,412,032) bit NAND Electrically Erasable and Programmable  Read-Only Memory (NAND E2PROM) organized as 528 bytes/264 words u 32 pages u 1024 blocks. The device uses  dual power supplies (2.7 V to 3.6 V for VCC and 1.65 V to 1.95 V for VCCQ ). The TC58DVM72A1FT00 has a 528-byte/264-words static register which allows program and read data to be transferred between the register and the memory cell array  in 528-byte/256-words increments. The Erase operation of TC58DVM72A1FT00 is implemented in a single block unit (16 Kbytes  512 bytes:  528 bytes u 32 pages/8k words + 256 words:264 words x 32 pages).

The TC58DVM72A1FT00 is a serial-type memory device which utilizes the I/O pins for both address and data  input/output as well as for command inputs. The Erase and Program operations are automatically executed making  the TC58DVM72A1FT00 most suitable for applications such as solid-state file storage, voice recording, image file memory for still  cameras and other systems which require high-density non-volatile memory data storage.
