T71L6808A

Features: · Supports eight 10/100Mbps Ethernet ports with RMII interface· Fully non-blocking shared memory architecture using page-based embedded SSRAM.· Incorporating with the output private buffering scheme to prevent HOL (head of line) blocking· Wire-speed store-and-forward switching with low s...

product image

T71L6808A Picture
See larger image
SeekIC No. : 004511452 Detail

T71L6808A: Features: · Supports eight 10/100Mbps Ethernet ports with RMII interface· Fully non-blocking shared memory architecture using page-based embedded SSRAM.· Incorporating with the output private buffer...

T71L6808A Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
T71L6808A
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Supports eight 10/100Mbps Ethernet ports with RMII interface
· Fully non-blocking shared memory architecture using page-based embedded SSRAM.
· Incorporating with the output private buffering scheme to prevent HOL (head of line) blocking
· Wire-speed store-and-forward switching with low switching latency. Automatic address learning, local frames filtering, and adjustable aging
· Embedded 1K entries of look-up table
· Supports full and half duplex operations
· Link, speed and duplex status are auto-detected via MDIO
· Auto-negotiated Full-duplex flow control by writing the ability via MDIO to external PHY
· Supports IEEE 802.3x flow control for full-duplex operation
· Supports back-pressure flow control for half-duplex operation
· Serial EEPROM interface for auto-configuration
· Broadcast storm control
· Port trunking & load sharing
· Port-based VLAN
· Port monitoring(snooping or mirroring)
· Supports port priority per port basis QoS
· Only one 50MHz OSC
· 128-pin PQFP, 3.3V CMOS technology


Pinout

Connection Diagram


Description

The T71L6808A is an octal-port 10/100Mbps dual speed Ethernet switch integrated both with an embedded SSRAM and a 1K entries of address table. A high performance Fast Ethernet switch, fully complies with the IEEE802.3, 802.3u and 802.3x specifications, can be implemented using the T71L6808A with physical devices. The T71L6808A is intended for applications to stand-alone switch for low-cost SOHO market.
