Product Details

Description



Features:

ARM7/TDMI
• Industry standard Real time OS: VxWorks
• Network Protocol Stack
• TCP/IP, UDP, TFTP, DHCP, HTTP server
• Ethernet/PC communication drivers
• High Level Chip Control
• Stack management
• SNMP (optional)
• Application Specific MIBS
• Signalling Protocol
• MGCP, H.323 (including H.450), SIP

D950 Voice Codec Unit (VCU) features:
• G.711 Packetized PCM
• G.729AB, 8kbps CS-ACELP
• G.726, 16-40 kbps ADPCM
• G.723.1a, 6.3/5.3 kbps MP-MLQ
• Encoding and decoding of PCM sample frames
• Packing/unpacking of compressed information in Codewords
• Fax Modem : T.38 Fax Relay, V.21, V.17,V.27ter and V.29 fax datapump
• Data Modem: V.34 datapump
• Rate selection
• High performance voice activity detector (VAD)
• Comfort noise generator (CNG)
• G.165 32 ms Line & acoustic echo canceller
• Low latency system implementation


Pinout

Connection Diagram


Specifications

Parameter Value
Supply Voltage(Vcc) -0.5 V to 7.0 V
Input Voltage -0.5 V to VCC + 0.5 V
Output Voltage -0.5 V to VCC + 0.5 V
Storage Temperature -65  to 150(-85 to 302)
Ambient Temperature 0to 70(32 to 158)
ESD Protection 2000V



Description

STMicroelectronics' STLC1502 is a high performance VoIP processor specially targeted for the time effective design of IP-Phones and analog gateway applications bundled with a comprehensive embedded software solution.

When used in the Enterprise LAN IP Phone space,this device STLC1502 enables the augmentation and replacement of raditional telephone systems with network based communications systems running over local and wide area IP networks. To design an IP phone,the only other parts required will be an analog interface,some optional Flash memory for upgradable software and Fast Ethernet physical layer devices.The ST complete IP Phone reference design includes standards compliant Application Programming Interfaces (APIs), protocol management software and software development tools.

The STLC1502 also has all the proper interfaces to be a cost effective solution for Small Gateway applications.ST also offer a complete SW reference design for Small Gateway applications.

Hence, the STLC1502 enables a superior and cost effective platform development for IP-phones as well as voice gateway applications, providing developers with a low risk, rapid time to market solution.

The STLC1502 integrates low power D950 DSP with a ARM7/TDMI MCU and a dual port 10/100 Base-T switched Ethernet media access control interface.

The main characteristics of the STLC1502 IP processor are as follows:
   • HCMOS7 technology
   • Power supply: Core 2.5 V and I/O: 3.3 V
   • Industry standard 32-bit RISC microprocessor (ARM7/TDMI core)
   • 16-bit, fixed point 120 MIPs DSP (D950)
   • Two 10/100 Base-T Ethernet MACs
   • VLAN support
   • Ethernet Bridge
   • JTAG
   • Smart power management
