PO74G14A

Note: stresss greater than listed under Maximum Ratings may cause permanent damage to the device. This is a stress rati rating only and functi tional operation of the device at these or any other conditi itions above those indicated in the operati rational secti sections of this speci ecificati ication is not implie lied. Exposure to absolute te maximum rati ting conditi itions for extended periods may affect relia reliabili ility spec ecificati ication is not implie lied.

Potato Semiconductor's PO74G14A is designed for world top performance using submicron CMOS technology to achieve 1.125GHz TTL /CMOS output frequency with less than 1.8ns propagati tion delay. This hex inverter contains six independent inverters designed for 1.65-V to 3.6-V VCC operation. The PO74G14A performs the Boolean function Y= A. Inputs can be driven from either 3.3V or 5V devices. This feature allows the use of these devices as translators in a mixed 3.3V/5V system environment.
