PMB2100RV1.1

The PMB2100RV1.1 is one member of the PMB2100 that is designed as the VCO device and is can be used in Dualband GSM applications with Infineon´s SMARTi/SMARTi+ chipset such as LO1 for Dualband GSM transceivers with SMARTi/SMARTi+.

Features of the PMB2100RV1.1 are:(1)Fully integrated, monolithic solution; (2)Very small outline and low profile TSSOP10 package.; (3)Balanced outputs; (4)Power down function; (5)Supply voltage 2.65 - 2.95V; (6)-20°C to +75°C operational temperature range.

The absolute maximum ratings of the PMB2100RV1.1 can be summarized as:(1)Supply voltage: -0.3 to 4.0 V;(2)Input voltage: -0.3 to VCC+0.3 V;(3)Output voltage: VCC V;(4)Junction Temperature: 125 °C;(5)Storage Temperature: -40 to 125 °C;(6)Thermal Resistance: 200 K/W;(7)ESD integrity: 1 kV. If you want to know more information about it, please download the datasheet in www.seekic.com or www.chinaicmart.com .
