PI6C185-00

(Above which the useful life may be impaired. For user guidelines, not tested.

Storage Temperature ......................................... 65°C to +150°C
Ambient Temperature with Power Applied ........... 0°C to +70°C
3.3V Supply Voltage to Ground Potential ............. 0.5V to +4.6V
DC Input Voltage .................................................. 0.5V to +4.6V

Note:
Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

The PI6C185-00 is a high-speed low-noise 1-7 non-inverting buffer designed for SDRAM clock buffer applications.

This PI6C185-00 buffer is intended to be used with the PI6C10X clock generator for Intel Architecture-based Mobile systems.

At power up all SDRAM output are enabled and active. The I2C Serial control may be used to individually activate/deactivate any of the 7 output drivers.Note of PI6C185-00:
Purchase of I2C components from Pericom conveys a license to use them in an I2C system as defined by Philips.
