PI6C180B

Above which the useful life may be impaired. For user guidelines, not tested.

Storage Temperature ............................................................. 65°C to +150°C
Ambient Temperature with Power Applied .............................. 0°C to +70°C
3.3V Supply Voltage to Ground Potential .............................. 0.5V to +4.6V
DC Input Voltage .................................................................... 0.5V to +4.6V

Note: Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

The PI6C180B, a high-speed low-noise 1-18 noninverting buffer designed for 140 MHz SDRAM clock buffer applications.

At power up all SDRAM output are enabled and active. The I2C Serial control may be used to individually activate/deactivate any of the 18 output drivers.The output of PI6C180B enable (OE) pin may be pulled low to put all outputs in a Hi-Z state.Note:Purchase of I2C components from Pericom conveys a license to use them in an I2C system as defined by Philips.
