PI6C1202

Storage Temperature .............................................................. -65°C to +150°C
Ambient Temperature with Power Applied .................................. 0°C to +70°C
Supply Voltage to Ground Potential (Inputs & Vcc only) ......... -0.3V to +7.0V
DC Input Voltage ...................................................................... -0.5V to +7.0V
DC Output Current ............................................................................... 120 mA
Power Dissipation ................................................................................... 1.0 W

Note:Stresses greater than those listed under MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

The PI6C1202 is an advanced CMOS clock generator designed specifically to support pixel clock generation in low-cost laser printers. Capable of generating highly stable clock frequencies up to 120 MHz, this PI6C1202 device supports printer engines with dot resolutions of 1,200 dpi and above. Page speeds may range from 4 pages per minute to better than 60 pages per minute.Mixed-line resolution supports half-toning and gray scale operations (low-resolution text mixed with high-resolution images) and minimizes controller memory utilization.
