PBL38571

PBL 38571 is a monolithic integrated speech transmission circuit of PBL38571  for use in electronic telephones and as DECT line interface with balanced in - and output. It is designed to accomodate either a low impedance dynamic microphone or an electret microphone that can be supplied from the circuits own DC - supply. A signal summing point at the transmitter input is available. An internally preset line length compensation of PBL38571 can be adjusted with external resistors to fit into different current feed systems as for ex. 48 V, 2 x 200 ohms, 48 V, 2 x 400 ohms and 48 V, 2 x 800 ohms.The line regulation can be shut off in low mode. Application dependent parameters such as line balance, side tone level, transmitter and receiver gains and frequency responces are set independently by external components which means an easy adaption to various market needs. The setting of the parameters, if PBL38571 carried out in crtain order will counteract the interaction between the settings. It features high line current capability on a small footprint. Function compatible with the PBL 3781 family of speech circuits.
