NTHD4P02FT1G, US $ .11-.29 , ON Semiconductor, NTHD4P02FT1G DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 00148418 Detail

NTHD4P02FT1G: MOSFET -20V -3A P-Channel w/3A Schottky

NTHD4P02FT1G Data Sheet

US $ .11~.29 / Piece | Get Latest Price

Part Number:: NTHD4P02FT1G
Mfg:: ON Semiconductor
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~500

Unit Price
$.29
$.2
$.16
$.11

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

NTHD2102P evaluate
Features: • Offers an Ultra Low RDS(on) Solution in the ChipFET Package• Miniature Chi...
NTHD2102PT1 evaluate
MOSFET -8V -4.6A P-Channel
NTHD2102PT1G evaluate
US $.23 - .36 / Piece

MOSFET -8V -4.6A P-Channel

Product Details

Quick Details

Transistor Polarity :	P-Channel	Drain-Source Breakdown Voltage :	20 V
Gate-Source Breakdown Voltage :	+/- 12 V	Continuous Drain Current :	2.2 A
Resistance Drain-Source RDS (on) :	155 mOhms at 4.5 V	Configuration :	Single Dual Drain
Maximum Operating Temperature :	+ 150 C	Mounting Style :	SMD/SMT
Package / Case :	Chip FET	Packaging :	Reel

Description

Mounting Style : SMD/SMT
Packaging : Reel
Transistor Polarity : P-Channel
Maximum Operating Temperature : + 150 C
Drain-Source Breakdown Voltage : 20 V
Gate-Source Breakdown Voltage : +/- 12 V
Configuration : Single Dual Drain
Continuous Drain Current : 2.2 A
Package / Case : Chip FET
Resistance Drain-Source RDS (on) : 155 mOhms at 4.5 V

Parameters:

Technical/Catalog Information	NTHD4P02FT1G
Vendor	ON Semiconductor
Category	Discrete Semiconductor Products
Mounting Type	Surface Mount
FET Polarity	P-Channel
Drain to Source Voltage (Vdss)	20V
Current - Continuous Drain (Id) @ 25° C	2.2A
Rds On (Max) @ Id, Vgs	155 mOhm @ 2.2A, 4.5V
Input Capacitance (Ciss) @ Vds	300pF @ 10V
Power - Max	1.1W
Packaging	Tape & Reel (TR)
Gate Charge (Qg) @ Vgs	6nC @ 4.5V
Package / Case	8-ChipFET?
FET Feature	Diode (Isolated)
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	NTHD4P02FT1G NTHD4P02FT1G NTHD4P02FT1GOSTR ND NTHD4P02FT1GOSTRND NTHD4P02FT1GOSTR
