NJU6060

Features: · Controls the 3-color LED Separately (ILED=10mA x 3 outputs)· Built-in PWM Luminance Control (32 steps x 3)· Built-in 8bit serial Interface Circuit· Built-in Oscillation Circuit· Operating Voltage for Step-up Circuits : 2.4V to 5.5V· Package : SSOP-10· CMOS TechnologyPinoutSpecification...

product image

NJU6060 Picture
See larger image
SeekIC No. : 004434407 Detail

NJU6060: Features: · Controls the 3-color LED Separately (ILED=10mA x 3 outputs)· Built-in PWM Luminance Control (32 steps x 3)· Built-in 8bit serial Interface Circuit· Built-in Oscillation Circuit· Operatin...

NJU6060 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
NJU6060
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/8

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Controls the 3-color LED Separately (ILED=10mA x 3 outputs)
· Built-in PWM Luminance Control (32 steps x 3)
· Built-in 8bit serial Interface Circuit
· Built-in Oscillation Circuit
· Operating Voltage for Step-up Circuits : 2.4V to 5.5V
· Package : SSOP-10
· CMOS Technology


Pinout

Connection Diagram


Specifications

PARAMETERS SYMBOL CONDITIONS RATINGS UNIT
VDD Power Supply VDD VDD terminal -0.3 to +6.0 V
Driver Off Break Down Voltage Voffmax LED1, LED2, LED3 terminals 7.0 V
Driver On Break Down Voltage Vonmax LED1, LED2, LED3 terminals 5.5 V
Input Voltage VIN1 CSb, DATA, CLK, RSTb, OSC
Terminals		 -0.3 to VDD+0.3 V
Power Dissipation Pdmax Ta=25°C 250 mW
Operating Temperature Topr   -40 to +85
Storage Temperature Tstg   -55 to +125
Note1) VSS = 0V to all conditions
Note2) If the LSI was used out of the absolute maximum ratings, LSI is damaged completely and the riliability become
poor. The LSI is used on the electrical characteristics is recommended strongly for normal operation.


Description

The NJU6060 is an RGB LED driver with PWM control. It contains PWM (pulse width modulation) controller, LED drivers, 8-bit serial interface, etc. Each of the R (red), G (green) and B (blue) outputs produces 32 levels individually so that the RGB LED emits 32,768 colors (32 x 32 x 32).

It requires only four external components such as three resistors for LED current adjustment and the one for oscillation,which enables the NJU6060 to save PCB space. The NJU6060 is suited for a large number of applications such as cellular phones, car stereo sets, household appliances, illumination equipment, etc.
