MNCOP681-X

Supply Voltage (Vcc) ............................................6V
Voltage at Any Pin........................-0.3V to Vcc +0.3V
Total Current to Vcc (Source)...........................40mA
Total Current from GND (Sink)..........................48mA
Storage Temperature Range............-65 C to +140 C
Note 1: Absolute maximum ratings indicate limits beyond which damage to the device may occur. DC and AC electrical specifications are not ensured when operating the device at absolute maximum ratings.

The COP681 and COP680 are members of the COPS 8-bit microcontroller family. They are fully static parts, fabricated using double-metal silicon gate microCMOS technology. This low cost microcontroller is a complete microcomputer containing all system timing, interrupt logic, ROM, RAM, and I/O necessary to implement dedicated control functions in a variety of applications. Features of COP681 and COP680   include an 8-bit memory mapped architecture, MICROWIRE/PLUS serial I/O, a 16-bit timer/counter with capture register and a multi sourced interrupt. Each I/O pin has software selectable options to adapt the COP681 and COP680 to the specific application. High throughput is achieved with an efficient, regular instruction set operating at a 1 microsecond per instruction rate.
