MNCOP680-X

Supply Voltage (Vcc)....................................6V
Voltage at Any Pin...............-0.3V to Vcc +0.3V
Total Current to Vcc (Source)..................40mA
Total Current from GND (Sink).................48mA
Stroage Temperature Range..-65 C to +140 C
Note 1: Absolute maximum ratings indicate limits beyond which damage to the damage to the device may occur. DC and AC electrical specifications are not ensured when operating the device at absolute maximum ratings

The COP680 and COP681 are members of the COPS 8-bit microcontroller family. COP680 and COP681 are fully static parts, fabricated using double-metal silicon gate microCMOS technology. This COP680 and COP681 low cost microcontroller is a complete microcomputer containing all system timing, interrupt logic, ROM, RAM and I/O necessary to implement dedicated control functions in a variety of applications. Features include an 8-bit memory mapped architecture, MICROWIRE/PLUS serial I/O, a 16-bit timer/counter with capture register and a multi sourced interrupt. Each I/O pin has software selectable options to adapt the COP680 and COP681 to the specific application. High throughput is achieved with an efficient, regular instruction set operating at a 1 microsecond per instruction rate.
